OS:Motor-Alternator Self-Looped System by Joe Tomicki

With the advent of rebuilt alternators, people are having cheaper options while choosing an alternator for their car or other vehicles, other than the branded ones like Valeo alternator or Delco Remy alternator. The rebuilt alternators have newly installed springs, bearings, diedo trio, slip rings and a voltage regulator. The replacement alternator just died. Pure Energy is still the cheapest option out there, but I don't want to keep replacing alternators every two years (I love the car and plan on keeping it until it dies.). I know that many of you may have used the Pure Energy alternator. My question is, have you had a similar problem?

Lasted edited by Andrew Munsey, updated on June 15, 2016 at 1:10 am.

  • 7 errors has been found on this page. Administrator will correct this soon.
  • This page has been imported from the old peswiki website. This message will be removed once updated.
.]]

See There was an error working with the wiki: Code[1] -- point to this being bogus

by Congress:Founder:Sterling D. Allan

Pure Energy Systems News

December 4, 2012

We just may have finally found the hero guy with a super-simple technology that he is willing to share with the planet, that is capable of powering a home using locally available, off-the-shelf components.

His particular system outputs 1500 Watts, which is enough to power a modest home, if the peak usage is carefully budgeted. A larger inverter could be fitted to the system for higher peak outputs. And the system can be set up inside the home, protected from the elements and vandalism.

The cost for components will be in the low thousands of dollars, and could even be in the low hundreds of dollars for those who are thoroughly familiar with rejuvenating batteries and sourcing good used components.

Overview

'Joe Tomicki has a system [full There was an error working with the wiki: Code[2] below] that entails hooking up a motor to an alternator that powers a bank of batteries which powers a house through an inverter (similar to a solar setup). The three batteries in series that power the drive motor are manually topped off, as needed, through a battery charger that also plugs into the inverter.'

Every community has someone who can source and assemble these for people locally, not just creating affordable, clean energy, but also creating jobs.

A shortcoming of the system as presently constituted is that it requires manual monitoring and switching. Perhaps the electrical engineers and hardware programmers among you could engineer a self-monitoring and automatic-switching system that removes the human oversight requirement.

Energy Source

As for where the energy is coming from, my best guess is that this is a variation of the Directory:Motor-Generator Self-Looped with Usable Energy Left Over system we have been featuring for a few months in our Top 5 Exotic Free Energy Technologies listing.

Sold Three

Joe told me he has had this design functioning for about four years now, and he has sold three. He charged $1400 for the motor-alternator set-up with pullies, and the customers sourced the batteries, inverters, and battery charger.

Went 40 Cycles on One Charge

Joe also said that on the first system he built, the bank of 10 batteries on the output side went through 40 charge-discharge cycles before he had to replenish the three input batteries from the output of the bank of 10 batteries. That was probably stressing the batteries, taking them lower than they should go, and he would not recommend that for the longevity of the system.

Calling for Replications

Given the short time-fuse we are on with society's downward spiral into the financial cliff trap that the powers that be have engineered for us, to turn us all into slaves, I'm going ahead and sharing what information I have now, without first taking the time to fully vet the technology.

I'm opening this up to you, our audience, to help us validate this. Quite a few of you have all the needed parts already, or you can get them easily.

Who will be first to replicate Joe's set-up? Who will be first to boost it to 10 kW? Who will be first to wrap some automated switching into the system so that it doesn't have to be manually switched?

Open Source

While Joe is willing to just give this away to the planet, I have talked him into accepting revenue from it so that we can set a precedent for other inventors who might also have simple technology, but who might not be so willing to just hand it over, getting nothing for it in return.

If you go commercial with this technology, whether from selling plans, translations, kits, components, completed units, manufacturing, distribution, franchises, etc., we just ask that you remit to NEST at 5% royalty. Tomiki has agreed to the terms of us sharing 60% of the revenue with him, with NEST retaining 40% for the administration of this project and enabling of similar projects.

Demonstration

Tomichi lives in the northern Dallas, TX, USA area. He is willing to allow someone to come verify his technology. We are looking for someone to visit him on behalf of NEST / PES.

Unfortunately, he doesn't presently have enough output batteries to do a demonstration. He said he needs at least 300 Ah worth on the bank end. He has the rest of the equipment.

Regarding the other three units he sold, he said that as far as he knows, one of them ran for at least two years, continuous.

Joe also said that as of now, he has not used an outside source of power to recharge any of the batteries. Yet he said that he once recharged the three 26 Ah input batteries using one 76 Ah battery.

Interview with Joe

All of this, including a description of the components needed, as well as his agreeing to these terms, is in an interview (mp3) Joe had with me on the evening of December 3, 2012. We had this page up and in our news in just over 12 hours from the time I talked to him about what he had. He first called me on November 27, 2012, and mentioned briefly what he had. I suggested he take a look at our Directory:Motor-Generator Self-Looped with Usable Energy Left Over page and then phone me back, to see if it is that type of system. He hadn't called back yet, so I phone him on the evening of December 3 to follow up.

Implementation

Be aware that local laws are likely to have provisions about the installation of power supplies in a home. You need to take precautions to adhere to those provisions in the spirit of safety, both for the device users as well as the linemen who service the grid. Qualified electricians should be utilized for installing any home or business power systems. Any 'emergency generator' scenarios should be sure to not involve connection to the grid.

Legal

This information is being presented for educational purposes.

PES / NEST cannot assume liability for what people do with these plans. You assume all risks for any experimentation and deployment you pursue.

Cautions

While this set-up is quite safe, there are some dangers to be aware of and to protect against:

Rapidly turning motor-alternator-belt apparatus.

Sparks from batteries being shorted can cause fires or injury or explosions.

Electricity can be dangerous if not handled properly.

Leaking battery acid

# # #

Official Websites

This present page at PESWiki is the official destination for this open source project.

  • 1:
  • 2:
  • 3:

Instructions

Assembly Photos

Joe provided these photos on the afternoon of December 4, 2012, shot that day. An explanation follows.

Click There was an error working with the wiki: Code[3] for enlargement.

- - - -

Click There was an error working with the wiki: Code[4] for enlargement.

- - - -

Click There was an error working with the wiki: Code[5] for enlargement.

- - - -

Note that presently, Joe does not have a full set of batteries. So on the output side, he presently only has one battery, just as a place holder for where he suggests that ten should go.

Also, the batteries in these photos are only 26 Ah, not 100 Ah.

The large black device is the inverter. On top of it is the 36-V battery charger.

Diagrams

Click There was an error working with the wiki: Code[6] for enlarged drawing by Directory:James Rodney of Directory:New Energy Systems Trust (NEST).

- - - -

Click There was an error working with the wiki: Code[7] for enlarged drawing.

Assembly Overview

# DC Motor: The DC motor is connected via V-Belt in a 2.5:2.75 ratio to the 63-amp DC Alternator, at least 24 inches away from the motor.

# Alternator: The DC Alternator charges up a bank of ten 12-V, deep cycle batteries in parallel, when the bank gets below a certain voltage level, bringing it back up to 'full.' It's best if the battery bank is not be under load while being recharged by the alternator.

# 10-battery bank: The bank of 10 batteries runs a 1500 W pure sine wave inverter.

# Inverter: The inverter provides AC power to the home. (Any DC appliances in the home, such as computers, could be powered directly from this battery bank.) The inverter also powers a battery charger.

# Battery Charger: The 36-volt battery charger charges the three 12-V batteries in series when it gets below a certain threshold. The three batteries should not be powering the motor while they are being recharged.

# 3-battery series bank: Three 12-V, deep-cycle batteries in series (for 36V) power the 1000 W DC motor

# Repeat of the above.

No external energy input is required. This system can allegedly run until one of the components needs servicing.

Components

Motor

Electric 36-V 1000-W, brushed motor (could probably also use brushless). Spins at 3000 rpm.

Motor nameplate:

36-V

speed rating: 3000 rpm

rated current: 35.6 Am

output: 1000 W

Source: UltraMotors.com

Also from:

(not confirmed by Joe yet) http://www.petrolscooter.co.uk/electric-motor-36-volt-1000-watt-11t-8mm.html

Alternator

63-Amp, by GM, with built-in regulator.

Output: 12-V

Pulley

The Motor and Alternator are attached via a V-Belt pulley using standard hardware.

In his present device, the Motor pulley is approximately 2.5 inches in diameter, and the alternator pulley is approximately 2.75 inches in diameter.

The distance between the motor and alternator shafts should be at least 24 inches. If they are closer, the efficiency of the effect drops off rapidly.

There needs to be a way to tighten the belt.

Base

The Motor and Alternator are attached to a wood base (2'x8' lumber approximately 30 inches long). The base should not contain electricity or magnetism-conducting materials.

10-Battery Array

The battery array to store the output power from the alternator consists of ten 12-volt, deep cycle, 100 Amp-hour batteries as are typically found in a solar or wind array for storage. They are wired in parallel using 6-gauge wire.

This array doesn't have to be 10 batteries. It could be more, it could be as few as two. Even one would probably be adequate to demonstrate the principle. The number of batteries depends on the storage and output need. The more batteries there are, the longer they will take to recharge, and the longer the charge will last before requiring recharge.

Instead of purchasing new deep-cycle, 12-V batteries, which can cost $250 USD each (Google), you might consider refurbishing old batteries using Bedini's Directory:Renaissance Charge Device by Energenx technology that can restore them to sometimes better than factory spec condition.

Inverter

Joe uses a 1500 W, pure sine-wave inverter, by PowerBright.

The brand is not important, but it needs to be 'pure sine-wave' in order to properly power the battery charger, which might be messed up with a 'modified sine wave inverter.'

Battery Charger

36-volt charger 4 Amp

Make: Teking

Recharging of the three batteries takes around 3 hours.

Operation

'The 2 wires on the side of the alternator need to be hooked up 1 to ground and 1 to the positive.'

The 10-battery bank should be recharged when it drops below 11.2 Volts.

Joe says it is capable of running for 11 hours at 1500 W continuous output.

The 36-volt array should be recharged when it drops below 38 volts (full is between 40 and 44 V, depending on the battery specs).

Avoiding extremes of high and low charge on the batteries enables them to last much longer.

During continual usage of the system, recharging of the 10-battery bank typically happens daily, depending on usage. Ditto for the 3-battery bank.

Proposed Tests

Test performance variation by changing the following:

Distance between Motor and Alternator

Orientation of Motor and Alternator

V-belt pulley diameter ratio modifications from low to high ratio away from 1:1 in both directions. Find sweet spot(s).

Try different sizes of motor, alternator, batteries, inverter, battery chargers.

See if most of the batteries can be removed from the system so that it is closer to the self-looped motor generator paradigm, cutting costs and maintenance on batteries.

Alternator

Variations

Key Elements

Many of the above components are likely to have a wide degree of latitude, but some things are likely to be fundamental to evoking the effect that allows free energy to show up from the environment.

The size (power) of the DC motor and the size (power) of the DC alternator are probably important, and until the variation curves are plotted, it would be best to stay as close to those parameters as possible.

The base holding the motor and generator should not be made of electromagnetic conductive material. Wood is recommended.

Scooter

This technology was actually discovered by Joe while modifying a scooter.

He combined the components from two scooters. On the front wheel was one motor/generator, and on the back was another. He would switch between the two so that one was being charged while the other was powering the scooter.

He had the throttle for one on the right handle bar, and the throttle for the other on the left handle bar. When the charge (as shown on the charge indicator gauge) for the driver motor got below a certain point, he would switch to the other throttle, so now the system that had been functioning as a generator was not functioning as a motor.

He claims to have been able to travel 1300 miles on one charge using this setup. He could get in several days of riding, with 8 hours of travel per day.

He then thought that maybe he could use this principle to power a house. He used the 1000-W motor from the scooter in the home power system.

One of the bikes he scavenged was a Currie Asteroid with an Ultra Motor 1000 W motor. The other was a Schwinn S500. The batteries used a BlueSky controller.

Supplemental Information

Profile: Joseph Edward Tomicki

Joe is a machinist by trade. For 30 years, he has been a CNC Machinist, tool and dye maker. 'I can make anything mechanical.' Recently he was employed making aircraft parts.

Pure Energy Alternator Review

He currently lives with his parents north of Dallas, TX.

Replications

List your replication accomplishments here: good or bad. PESWiki is publicly editable (after you get a username set up by request). If you happen to successfully replicate this set-up, please call me: 801-407-1292, so we can get the news about it up here right away.

This system by Joe Tomicki is yet another independent arrival at a phenomenon we've been compiling at Directory:Motor-Generator Self-Looped with Usable Energy Left Over.

In the News

Latest: There was an error working with the wiki: Code[1] > This Week in Free Energy™ > This Week in Free Energy™: August 15, 2013 - Best Kept Secret: Geoffrey S. Miller's Energybat Labs / Interview • Keelynet Summarizes LeClair's 3.4x Overunity Cavitation Report • Wind company willing to use their turbines as a decoy • Lindemann announces 'Open System Thermodynamics' lecture • Joe Tomicki wants his Q-mo-gen validation • Chuck Pierce' Regen demo • GlobalBEM Fundrasier for Boulder Conference (FreeEnergyNews) Latest / There was an error working with the wiki: Code[1] > Directory:Motor-Generator Self-Looped with Usable Energy Left Over > OS:Motor-Alternator Self-Looped System by Joe Tomicki (Probably bogus) - An inventor from Dallas, TX, is openly sharing a system that entails hooking up a motor to an alternator that powers a bank of batteries which powers a house through an inverter (similar to a solar setup). The three batteries in series that power the drive motor are manually topped off as needed through a battery charger that also plugs into the inverter. (PESWiki December 4, 2012)

Forums

http://groups.yahoo.com/group/altern8r - An open source forum for replicating, characterizing, optimizing, engineering, theorizing, manufacturing, and distributing the design by Joseph Edward Tomicki (Launched by SDA, December 4, 2012)

Or send an email to [mailto:altern8r-subscribe@yahoogroups.com?subject=subscribe altern8r-subscribe@yahoogroups.com] and respond to the auto-responder message to join the email forum.

Comments

Feel free to post your comments down below, or go to one of the forums above and comment/discuss there.

Phase Angle is Key

On December 04, 2012 12:40 PM OS:Vernon Roth's Alchemical Hydrogen wrote:

That phase angle is key, Sterling.

I have seen some O-U tech working on phase angle coupling between motors and generators.

But tuning and reproducing is a bear. Politely speaking.

Has anyone else seen this operational?

Some relatives of mine poured a lot of money into a guy making this exact setup, and it never actually panned out. They asked me to work with him.

I was able to have some success by putting one of Sonne Ward's implosion chargers in the system so the batteries charged faster with less power. But without it, there was no over-unity. Even with it, the motor was over taxed by the alternator and the system did not last more than a few days.

Godspeed.

I Don't See Where the Energy is Coming From

On December 4, ~2 pm MDT, Directory:Karl Palsness, a Tesla technology researcher, said:

There is no phase angle coming off a DC motor.

There is an AC component in the alternator, but no coupling between the motor-alternator.

There is nothing unusual about the components in this system. If anything, you would expect it to be very inefficient. Regular V-belts are very inefficient.

In this set-up, I don't see where energy from the environment could be coming into the system.

At least everything is easily measurable. If this system does work, you should be able to pinpoint where the excess energy is coming into the system.

In the scenarios I've witnessed, the motor has to be specially wound, or use some kind of specialized electronics. That's where we get our overunity effect.

If you run a DC motor in low rpm, you can get overunity, but it will burn up if you do it for more than a few seconds.

The guy in Indonesia is using phase angles [on an AC motor] with high current, and his machine is running hot.

[P.S. I should mention that the funding source for Karl's research, which he's been doing full-time, funded, for a decade, recently went away, so he's had to let his employees go and find other work for himself to support his family. Prior to the money running out, he had just procured some equipment to run some tests on a system not too dissimilar to this one. But that is now on hold.]

Why shouldn't it just run down over time?

On Dec. 4, 2012 6:49 pm [GMT-7], Directory:Gillis Patrick Flanagan wrote:

I can think of ways to improve it. A little bit like what John Bedini did a long time ago.

Question is: Why should it work at all? Why shouldn't it just run down over time? Are alternators OU?

I don't see any way to get over unity to keep it going.

Pure Energy Alternator Review Consumer Reports

[If it did work,] I would use two sets of batteries to drive it, using a voltage detection circuit and a relay to switch the inout battery sets when the voltage of the drive set goes down, you switch to the charged set and put the former set on charge. All automatic. The you just have to maintain the batteries on a periodic basis.

No Evidence to Support

On December 04, 2012 7:45 PM [GMT-7], Directory:Peter Lindemann wrote:

I have to agree with Mark and Jim. If the information you have provided is accurate, and the system is made from commercially available 'off the shelf' parts, including an electric motor, automotive alternator, batteries, an inverter, and a battery charger, then there is no reason to believe the system works. The 'efficiencies' of these components are well known, and not one of them has an efficiency greater than 90%. With a transfer of energy, from the first bank of batteries to the electric motor, to the alternator, to the second set of batteries, to the inverter, to the battery charger, and back to the first set of batteries, figuring 90% efficiency at each stage (a very generous estimate), the system could not exceed an aggregate efficiency of 54%. The system may be 'self-looped', but it will certainly not continue operating longer than the capacity of the batteries allow.

In the absence of any specifically identified 'environmental gain' mechanism, I can't imagine why you would entertain the idea that this 'might' be a genuine demonstration of a 'self-running energy supply'. From my cursory analysis, based on the information you have provided, there seems to be no evidence to support such a conclusion.

Overunity Unlikely

On December 05, 2012 5:53 AM [GMT-7], Directory:Matt Imber wrote:

This sounds like an interesting set-up. I don’t suppose the inventor is making claims of over-unity, as this sounds unlikely, unless the motor or alternator is modified like a Roto-Verter.

Zero Chance

On Wed, Dec 5, 2012 at 4:19 PM, Konehead wrote:

BELOW ZERO chance this set up is overunity, let alone be able to power a

house with it like he claims..

You might as well get a big stack of golf cart batteries, and run an

Pure Energy Alternator Review

invertor with it, then power your house with that..recharge those

batteries however you want to.

Where the heck is any overunity in this system at all??

ITs a standard DC motor turning a standard generator that chareges

batteris and invertor runs off the batteries. Big deal!

Free train sim pc. Just start backwards whats the effeciency and loss from that invertor?

Certainly not above 100%

Whats the effeciency and loss of that generator charging the battery

stack? Again, not even near 100% and when batteris are really depleted and

generator really has to work hard to charge, its much worse.

Whats the effeciency and loss from the motor itself while it chugs that

genrator under load?

Same thing with the motor, uder heavy load its going to draw lots of amps

get hot, be totally in-effecient maybe 20% (!)

I would agree with Peter L. in what he wrote probably about

50% effeciency at best, and lots lots worse under any sort of heavy load. Warblade game free. download full version for pc.

Red Flags

December 4, 2012 7:45 pm [GMT-7]

Those who would be inclined to believe in legitimate overunity claims don't see where the excess energy could be showing up in this system that has no modifications of standard equipment.

None of the three people who Joe said bought a system are reachable for confirmation, since their phone numbers were in a previous phone that has been lost. Their numbers are not stored elsewhere.

Why would a person who has worked for 30 years as a CNC operator be living at home with his parents, for at least the four year duration of the alleged existence of this device?

Joe's parents have no interest in this project.

The only available system is sans enough batteries to operate in a closed loop manner. It has never had a full set of batteries because the parents don't want Joe running their home on this thing. It is therefore not ready for giving a demonstration.

An intuitive didn't have a good feeling about this one from the start.

Unfortunately, after the first 24 hours of accumulating information about this, it appears that this one is most likely bogus. Joe never asked for any money, so the charge of 'fraud' is completely inappropriate.

Contact

We're looking for someone willing to serve as project coordinator.

See also

BEST

ENERGY TYPES

There was an error working with the wiki: Code[1]

There was an error working with the wiki: Code[2]

There was an error working with the wiki: Code[3]

There was an error working with the wiki: Code[4]

DEVICE TYPES

Directory:Electromagnetic (overunity)

There was an error working with the wiki: Code[5] | News:2006-2008:Electromagnetic

There was an error working with the wiki: Code[6]

There was an error working with the wiki: Code[7]

Pure Energy Alternator Review 2018

There was an error working with the wiki: Code[8]

- OS

- News:Open Source Minitool partition wizard quick format.

- Main Page

- PES Network Inc.

If twenty years ago someone would have told you to install a rebuilt alternators, then you would have found it to be bizarre as the concept of a rebuilt alternators did not exist. But things have changed in recent years. With the advent of rebuilt alternators, people are having cheaper options while choosing an alternator for their car or other vehicles, other than the branded ones like Valeo alternator or Delco Remy alternator.

The rebuilt alternators have newly installed springs, bearings, diedo trio, slip rings and a voltage regulator. After replacing these elements, the case of the alternator is sand-blasted and assembled again, making it ready to be tested.


The local rebuilders can be divided into two types:

  • Refurbishing with high-quality parts
  • Refurbishing with low-quality parts

Are Refurbished Alternators and Good?

There are many garage owners who will suggest you an unknown brand’s alternator to be installed in your vehicle. Such suggestions are only made when you insist to cut down costs with the repairs. But there are are many refurbished alternators that are branded, i.e., they are cheap and are refurbished by a reputed brand such as Valeo or Delco Remy alternators. This makes their refurbished alternators a bit more reliable than the unknown ones.

Why Should You Choose a Brand While Buying an Alternator?

While purchasing an alternator, people wonder if it is worth to buy from a branded name. We, being leading automobile spare parts supplier of some great brands like Valeo alternator and Delco Remy alternator, will suggest you that you always install a new and branded alternator in your car, in case of an alternator failure.

There are many vehicles who work on heavy duty and require prompt services. Such vehicles include ambulance, fire trucks and buses, that require a prompt movement with no breakdown while on duty. A branded alternator will provide a good strength and precision to work long hours.

Top Brands in India to Choose From

There are certain brands that are the most preferred among car manufacturers and producers, to make their cars to have an unmatched performance. We have mentioned a few brands that are the leader in providing superior alternators in the Indian market.

  • Bosch Electrical Alternator

Bosch is a European company that is well-known for providing high-quality automobile spare parts for decades. They began their journey in the automobile spare parts industry in 1927.

  • Valeo Alternator and Starter

Valeo provides quality alternators and starters for all generation cars. Brands like Ford, Fiat, Hyundai, Maruti, Toyota and more rely on Valeo Alternators.

  • Delco Remy Heavy Duty Alternators

Delco Remy alternators are generally used in heavy-duty vehicles. They are highly sturdy and provides the required strength to the heavy-duty vehicles.

  • Lucas TVS

Lucas TVS is a joint venture between the British company Lucas Plc., and the Indian company, TVS. Automobile spare parts of Lucas TVS is used in many equipments and passenger vehicles.

How Should You Find Quality Alternators at Reasonable Prices?

Pure Energy Remanufactured Alternators Review

There are a few suppliers in India that provide branded and quality alternators at a slightly reasonable price but you need to know how you should choose among them. While picking the ideal distributor, you should look for a company that has a remarkable reputation in providing better automobile spare parts. Such a distributor will have good expertise and knowledge and can help you pick the most suitable automobile spare parts, according to your vehicle and model. Choose Krishna Auto Electric. We have helped many in having superior quality products at great deals. Call us on +91 98 25063530 to inquire more about our products!
